Model# AM413FVT AM311H   AMH-RUT AM312 / AM412
Description Handheld Digital UV Microscope

Handheld Digital Ear scope

  Handheld Iris Scope
Handheld Digital Microscope
Resolution 1.3MP
1280x1024 pixels
0.3MP
640x480 pixels
  1.3MP
1280x1024 pixels
0.3MP
510*496 pixels
Interface USB 2.0 Output USB 2.0 Output   USB 2.0 Output NTSC, AVI output
Magnification 10~70x, 200x Continuous 10~50x Continuous   10~ 20x Continuous

10~ 200x Continuous

Color Taupe White   Taupe Black
Sensor 1/3” Color CMOS 1/4” Color CMOS 1/3” Color CMOS 1/4” Color CMOS
Video frame rate 15 frame-per-second @ 1.3M up to 30 frame-per-second 15 frame-per-second @ 1.3M N/A
Illumination Built-in 8 UV LED’s Built-in 4 white LED’s   Built-in 2 white LED’s Built-in 4 ( 8) white LED’s
Additional features LED on/off controlled by software LED on/off controlled by software   LED on/off controlled by software
(Micro Touch - Trigger button)

  (Micro Touch - Trigger button)
CD content DinoCapture application software CD with Instruction manual N/A
OS compatible Win 2000/XP, Vista and most MAC OS (please verify OS) N/A
Save file format BMP, JPG, AVI N/A
Regulatory approvals CE, FCC, ROHS
Body length 4"/ 10.2cm ~4 1/2" / 11cm   4.2" 4"/ 10.2cm
Body diameter 1.26 inches / 3.2cm max.
Cable length 6 feet / 180 cm
Body with cable 0.2 lbs / 95g +/- 10g 0.44 lbs 0.44 lbs
Total unit weight 0.6 lbs / 280g +/- 20g (not including manual) 0.84 lbs 0.84 lbs
Package dimension 6.5”x 6.5”x 2.5” / 16.5 cm x 16.5 cm x 6 cm
Package include

DinoLite digital microscope
Application Software CD
Cradle stand
Carry bag

DinoLite digital Ear scope
Application Software CD
Carry bag
  DinoLite digital microscope
Application Software CD

DinoLite digital microscope
Cradle stand
5V AC adaptor
Inout: 110v-240v
Output: DC 5V/500m
System require Intel Pentium III 1G MHz processor or faster
Windows 2000/XP, Vista
256 MB RAM
CD-ROM drive
16-bit color display monitor or higher
Available USB 2.0 port



Warranty 1 Year
Condition New
Packing Retail Box
Tech support Dealer or Bigc.com
Country of origin Taiwan
Master carton include 40 pcs
Master carton weight 28 lbs 30 lbs 34 lbs
